EARTH CAMPER

1. Queen Sized Bed: get a good night’s sleep on the high density, 150mm thick foam mattress.

2. Lighting: Abundant internal lighting; including roof, bedside and living room area lighting.

3. Under Bed Storage: Keep your clothing easily accessible or store your flip out table

4. Extra Storage: Side walls, overhead, and bedside are dressed with even more cargo organiser’s

5. Internal Access Door: Separate the inner sleeping area from the outside and keeps canvas separate from bed zone in tow mode or when packed up.

1. Living Area: Once opened, the Earth Camper has a stand up change zone and spacious living area with excellent ventilation.

2. Hard Flooring: The rear door transforms into a hard floor for the living area.

3. ARB Awning: Integrated into the camper body for improved aerodynamics, provides shade and shelter over the kitchen

4. 96L ARB Zero Dual Zone Fridge Freezer: To keep your food preserved.

5. ARB Slide Kitchen: Stainless steel bench with 2 burner propane Dometic cooktop with wind deflector and kitchen sink.

6. Kitchen Storage: Slide out pantry tray placing all your cooking essentials within reach.

7. Propane Bottles: 2x 11lb propane bottles securely stored and protected.

1. One-Piece Welded Exoskeleton: Designed to keep the body safe.

2. OME Nitrocharger Suspension: Purpose-built to go where you go.

3. 140L Water Storage: Dual tank to hold all the water you'll need.

4. 120W Solar Panel: Charge your Earth Camper whenever you are.

5. Rear Storage Locker: Perfect for spare parts, tools, wetsuits or even firewood.

6. Front Boot Storage: Generous space to pack your more readily accessed cargo

7. Jerry Can Holder: Ensure you are always good for fuel.

8. Maxxis All-Terrain Tires: Special ARB ‘EC’ edition 16” alloy wheels wrapped in Maxxis Razr All Terrain tires.

9. Stone Shield: Equipped with a stone shield at front, under center & rear for maximum protection.

10. Next-Level Drawbar Design: The drawbar comes complete with a Cruisemaster D035 hitch & handbrake, ARK XO extreme off road jockey wheel rated to 500kgs, 3500kg rated safety chain & G80 connector, as well as two ARK drop down stabiliser legs at the rear of the chassis.

11. Push Button Rear Door Activation: Open your trailer with a push of the button, transforming from a trailer to a free-standing living area complete with hard flooring & 280GSM canvas.

>>> Spacious Interior

With an impressive 37" internal head height (from the top of mattress to the ceiling), the Earth Camper’s internal living feels quite comfortable & spacious, more than what you may have expected from a compact unit of its size.

>>> Queen-Sized Bed

Sleeping on the road has never looked so good. Coming equipped with a comfortable, full queen-sized bed, you’ll be sure to get a good night’s sleep on the high density, 6" thick foam mattress.

>>> Dual Sirocco Fans

Stay cool on those hot summer nights. Quiet yet powerful 3 speed fan with timer and limitless 360° direction capability, these Sirocco fans will be welcomed when you’re getting your hard-earned rest.

>>> Built-In Dining Table

A flip out table provides an interior bench space during inclement weather events.

MORE:

• Window furniture with Pleated blackout curtains and flyscreen
• Tinted and tempered glass windows, gas strut assisted with 2 stage opening
• ‘EC’ edition world map on roof to track your adventures
• Abundant internal lighting; ambient roof lighting, 2x bedside reading lights & dimmable living room area light
• Loaded with tech; 2x bedside USB-C phone charging points, 3 x USB sockets, 2x 110v GPO’s
• REDARC control panel and BMS with mobile APP
• 2x internal drawer storage tray organisers
• Durable & replaceable EVA foam flooring on key step zones
• Textured powdercoat main floor for durability & easy cleaning
• Internally lockable internal access door with premium RTM fiberglass finish (overnight mode)

>>> ARB Slide Kitchen

ARB Patented, full size & freestanding Slide Kitchen comes equipped with a huge stainless steel bench space which remains available while cooking, as well as a 2-burner cooktop with included wind deflector and an integrated sink with tap

>>> Large Bench Space

Prepare your meals with ease with the convenience of ARB’s Slide Kitchen’s massive stainless steel bench top.

>>> 103Q ARB Zero Fridge Freezer

Included as standard is a giant 103Q ARB ZERO dual zone fridge/freezer, ensuring your supplies on the road are kept cool and secure.

>>> 39 Gal Water Tank

A large single rotomoulded water tank for all your potable water needs.

MORE:

• Fridge/freezer tie downs
• Spacious cutlery drawer
• Full extension lockout fridge slide w/ ARB cable run
• 1kg ABE dry fire extinguisher
• Sliding, lockable pantry drawer
• LED pantry light, dimmable and two color selectable
• 2 x USB power outlet and 1 x 110V double GPO in pantry zone
• Digital water level indicator
• Quality electrically operated water pump
• Lockable water fill point
• External tap outlet
• 2x 11 lb gas bottles
• Lockable gas bottle holder
• Tailor-fit storage bags available (optional extra)

>>> ARB Base Rack

Topped by a 1255×1455 ARB BASE roof rack, this is a great place to house recovery boards, kayaks/surfboards, additional solar panels or even some swags providing extra sleeping quarters for the whole family.

>>> Rear Storage Locker

Spacious, lockable rear wet storage locker. Perfect for spare parts, tools, wetsuits, or even kindling.

>>> Dual Jerry Can Storage

Ensure you’re always good for fuel or water when taking on the tracks with provision for two 5 Gal. jerry cans, that are also lockable to ensure your jerry cans are fixed.

>>> Versatile Drawbar Accessory Rails

The drawbar of the Earth Camper has been designed by campers, for campers. Incorporating accessory mounting rails to utilize otherwise untapped space, the drawbar comes complete with a Cruisemaster D035 hitch & handbrake, ARK XO extreme off road jockey wheel rated to 750kgs, 3500kg rated safety chain & G80 connector, as well as two ARK drop down stabiliser legs at the rear of the chassis.

>>> Roof Storage Lockers

LHS integrated roof compartment incorporates the ARB swing out awning (standard inclusion) and LED lighting

RHS integrated roof storage compartment suits the ARB Earth camper ensuite (optional extra) and LED lighting

MORE:

Unique storage compartments incorporated in each region & tailor fit cargo gear bags available for extended remote area travel (see accessories)

External

• 1255×1455 ARB BASE roof rack (compatible with accessories)
• Rear wet storage locker
• Provision for 2x 20L jerry cans (lockable)
• Roof storage compartment (if not equipped with Ensuite Room)
• Drawbar accessory rails – provision for drawbar storage

Internal

• Spacious front boot & essentials kit bag (standard inclusion)
• Custom soft storage bag, stackable in front of Spare tire storage compartment
• Large underbed storage drawer with anti-rollback
• Under drawer custom soft storage bag
• 4x large overhead pockets
• Bedhead cargo organiser – 10 pockets
• Bedside cargo organiser’s – 2 per side, water bottle storage
• Generous sidewall storage pockets – 2 per side

>>> 35" Extra-Long Trailing Arm

By maximising the length of each trailing arm to 900mm, our engineers were able to reduce strain on suspension components, extract greater wheel travel and ultimately provide a smoother ride and better traction.

>>> Vertically Oriented Shock Absorber

Installing the OME Nitrocharger shocks, and positioning them correctly in the Earth Camper, were key to ensuring a reliable and long-lasting suspension solution. The natural advantages of a vertically oriented shock absorber allow the shock to achieve 100% efficiency as any movement at the axle reflects directly on the shock.

>>> All Terrain Tires & Alloy Wheels

With the special ARB ‘EC’ edition 16” alloy wheels (Inc. spare) 16×5.5 +20 offset, fitted with Maxxis Razr 265/75/R16 or 31.6" All Terrain tires, the Earth Camper is set on a premium combination of rims and tires.

>>> 12" Electric Brakes

Quality Dexter 12” electric drum brakes, and having a wheel brace, bottle jack, spare center cap etc. included, you can rely on the foundation of the Camper Trailer going the distance and keeping you on track.

MORE:

• Patented 3-part, comprehensive independent suspension system, integrated with the Earth Camper’s exoskeleton chassis
• Wheel Hub stud pattern, 6 x 139.7 Toyota style (interchangeable)
• Quality Timken bearings, a spare bearing supplied standard in Essentials pack.
• Wheel brace, scissor jack, spare center hubcap supplied standard in Essentials pack.
• Mechanical components intentionally incorporate industry standard selections to simplify finding replacements in remote areas if necessary

>>> Fiberglass Reinfornced Polymer (FRP)

With a 100% wood free design, the Earth Camper’s body has been engineered to be both tough and lightweight.

>>> Insulated Design

Being well insulated for the keen adventurer, the Earth Camper’s walls & roof are 1" thick and packed with a foam core.

Along with this, the internal bulkhead has a 1.25" cladded foam core, and the interior comes complete with 2 x ARB dust suppression system, equipped with serviceable foam filters.

>>> Open Side Window & Flyscreen

Ventilation to your sleeping space is as easy as a push, with a 2 stage opening side window that also doubles as an escape hatch. Window furniture is a full cassette with pull down block out curtain and lift up flyscreen.

>>> ARB Awning

Equipped with a freestanding ARB Awning with poles included for wind and overnight use. The ARB Awning also includes an inbuilt LED ambient light for those late nights and internal awning housing to eliminate catching low hanging obstacles off road.

MORE:

• Durable fibreglass reinforced polymer (FRP) construction using RTM & HLU processes
• Durable gelcoat integrated color, cool grey (PMS415C)
• Lockable compression latches
• Gas strut or friction hinge assisted panel opening
• Included awning extension canvas to rear tent door
• 280GSM poly-cotton ripstop awning canvas
• Awning Wind Breaks available (optional extra)

>>> One-Piece Welded Exoskeleton

Designed to keep the body safe, our patented one-piece welded exoskeleton frame for superior strength over traditional RHS chassis. The exoskeleton creates a low centre of gravity and superior towing performance.

>>> Embossed From Body

Being embossed from the body of the Earth Camper itself, the exoskeleton provides rugged, roll cage-like protection to the body.

>>> Cruisemaster Hitch & Handbrake

The Cruisemaster DO35 Hitch & Handbrake equipped to the Earth Camper makes setting, equipping & detaching your RV a seamless task.

MORE:

• Patented one-piece welded tubular exoskeleton frame for superior strength over traditional RHS chassis
• 3.5" cylindrical, mandrel bent steel tube with a 1/8" wall thickness
• Multi-level coated, with tank dipped automotive e-coat inside and out then double layered, polyurethane (PU) black coating
• 4x welded on jacking points – 2 per side
• Drawbar accessory mounting rails
• Under Vehicle Protection for Camper (replaceable)
• Cruisemaster D035 hitch & handbrake
• 3500kg rated safety chain & G80 connector
• ARK XO extreme off road jockey wheel (500kg rated)
• Front stone shield
• Underslung mud flap & stone shield
• ARB mudflaps
• 2x ARK drop down stabiliser legs

>>> Rear Door

Via the push of a button, get into bed in less than 1 min! After a long day on the road or unfavourable weather, quick access to your sleeping quarters is paramount, and the Earth Camper delivers via it’s bespoke rear door design.

>>> Redarc Battery Management System

A REDARC Alpha 50 battery management system (BMS) comes included as standard. Controlled via a user-friendly in-cabin interface, have peace of mind the electrics are well managed.

>>> 100AH Lithium Battery

Powered by a huge 100AH Lithium Battery included as standard, the Earth Camper will have you powered for longer. Battery storage box is up-scalable to 300 AH.

>>> 120W Solar Panel

Charging the Earth Camper off grid has been thought through, coming standard with a 120W fixed roof mounted solar panel. Exterior input connection provided for additional portable external solar panel.

MORE:

• Push button, electronically dual-actuated rear door <1min
• External mounted Anderson plug solar input
• 7 pin trailer socket & Anderson DC-DC input
• 4x side clearance lights
• IP68 rated tail, brake, indicator, lights
• 110V mains power provision, with dual internal GPO outlets, main RCD & dual GPO outlet in front locker and external mounted 110V/15A inlet
• Pantry 12v; cig & USB socket
• Internal 12v; 2x USB-C, 6x USB
• Provision for REDARC RS3 type inverters 1200W or 2000W
• Dual temperature & dimmable gullwing door lighting
• Front storage compartment automatic sensor lighting

Interior

WEIGHT

EXTERIOR

• Webasto Airtop 2000 Diesel Heater system is mounted on custom ARB bracketry & includes a 20l HD Proquip jerry can as the fuel cell
• The Diesel Heater upgrade also includes the premium Webasto digital controller
• Awning Wind Breaks available in two sizes; narrow & wide
• Awning Wind Breaks are mounted using the included spreader pole

• Option to fit a 2nd Lithium Battery
• Earth Camper equipped with 1x 100AH Lithium as standard
• Battery tray on the Earth Camper can house a second battery if desired
• Min. 2x 100AH Lithium required for 2000w inverter
• Upgrading to RedVision, swaps out the standard REDARC Manager 30 interface
• Control accessories such as lights, fridges, TVs and inverters via the physical screen or even via your phone
• The RedVision control board, replaces the standard fit fuse block, water level indicator & battery isolator to centrally terminate all essential systems in one place
• REDARC Inverters power your 240v accessories whilst off grid
• ARB has engineered an inverter mounting bracket, capable of holding the majority of the REDARC range from 350w – 2000w inverters

• Partnership between hot water brand ‘Joolca’ and ARB delivers a tailor fit hot water & shower solution
• Joolca’s popular HOTAP V2 ‘Outing kit’, including the heater unit, colour coded hoses, ergonomic shower head & off grid water pump and filter, enables drawing water from nearby water sources (rivers, lakes etc)
• Neatly housed on an ARB made, swing out storage bracket
• Included in the kit is a tailor made storage bag, to conveniently store all hoses & accessories directly underneath the unit
• Complimenting the hot water shower upgrade is a spacious Ensuite Room
• Ensuite Room addition provides private and convenient sheltered space from the elements
• 2 stage doors & flyscreen on both sides and a central window

• ‘EC Edition’ storage bags have been crafted to ensure every item has a home
• Front Locker Storage Bag can be double stacked in the spare tyre compartment
• Pole Storage Bag conveniently houses the poles for the Awning, Ensuite Room & Awning Wind Breaks
• Canvas Storage Bag houses the all the Earth Camper canvas accessories; Awning roof extension, Ensuite Room & Awning Wind Breaks
• Foldable and features a sewn in vent for promoting airflow
• Earth Camper Pantry Draws available in 2x height storage bags (full and 1/2)
• Full height caters to taller food packaging
• 1/2 height is designed to work perfectly with the ARB Kitchen Organiser, promoting storage for shorter pantry item
• Both feature clear tops for great visibility, internal dividers, quality zips & ‘EC edition’ branding

• Specific Air Compressor Kit developed for the Earth Camper
• Specified braided hosing cut to length, remote air outlet chuck fitted next to the outside water tap
• Comprehensive range of air system accessories available; like tyre in/deflators, blow gun etc.
• Premium ARB Canvas Storage Cover stitched specifically to follow the contours of the camper
• Features a solar panel window allowing charge even when covered, zip able access to the electrical compartment without needing to remove cover & 4x tiedown cam buckles to ensure it stays secured in the wind
• The cover has 2 layers: Top layer; 300GSM 100% polyester with PU coating for increased weather & UV resistance and Bottom; 225GSM soft tricot brush material to protect the body work from scratches
